GLP1-g

PE conductor, insulation, high voltage and function testing device

The smallest safety tester in the world!

More than 50 device configurations as single- or multitesters for the most diverse testing applications and requirements.

Product consultant

You need a personal product advice?
Please use our direct contact:
+49 2372 901 25 40
Email request

Key-Facts

  • safety testers ALL-IN-1
  • world’s smallest safety test instrument with this power density
  • all test methods fully electronically controlled wear-free
  • automatic switching between test methods and test connections
  • fully automatic, semi-automatic or manual test sequence
  • fully automatic or manual high voltage adjustment via rotary wheel
  • operation via intuitive touch display
  • LabView driver
  • on table or mobile device in caddy
  • 19″ rack for automation
  • integrated test result memory
  • traceable factory calibration certificate included
  • safe according to EN50191
  • PLe, SIL3, Kat4 Safety circuit (depending on device variant and degree of risk)
  • high process reliability
  • remote control for automation
  • digital potential-free 24 V inputs/outputs
  • standard tester ex stock or very short delivery time

Variants

53 Device variants for solving your testing task.

Please select the desired test method:

List view
Compare

GLP1-g 120 | Test method » GB AC

type of testeronly PE/GB-resistance testers
PE/GB1–10 A˜ 6/12 Veff
test terminalsPE1, PE2
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 130 | Test method » GB AC

type of testeronly PE/GB-resistance testers
PE/GB1–30 A˜ 6/12 Veff
test terminalsPE1, PE2
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 140 | Test method » GB AC

type of testeronly PE/GB-resistance testers
PE/GB1–40 A˜ 6/12 Veff
test terminalsPE1, PE2
test connectionstest probe
 test socket at the rear, 10-pole
automation
deliveryin 5 business days

GLP1-g 141 | Test method » GB DC

type of testeronly PE/GB-resistance testers
PE/GB1–40 A˭ 12 V
test terminalsPE1, PE2
test connectionstest probe
 test socket at the rear, 10-pole
automation
deliveryorder-related manufacturing

GLP1-g 160 | Test method » GB AC

type of testeronly PE/GB-resistance testers
PE/GB1–75 A˜ 6/12 Veff
test terminalsPE1, PE2
test connectionstest probe
 test socket at the rear, 10-pole
automation
deliveryorder-related manufacturing

GLP1-g 220 | Test method » IR

type of testeronly insulation testers (IR)
insulation0–1 kV ˭ max. 10 GΩ
test terminalsL1, N, PE
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 320 | Test method » HV AC

type of testeronly high-voltage testers
high voltage AC0–6 kV˜ max.3 mA safety
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest pistols
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 321 | Test method » HV AC

type of testeronly high-voltage testers
high voltage AC0–6 kV˜ max.3 mA safety
test terminalsHV1, HV2
test connectionstest pistols, 2-pole
automation
deliveryin 5 business days

GLP1-g 330 | Test method » HV AC

type of testeronly high-voltage testers
high voltage AC0–6 kV˜ max. 100 mA
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest pistols
 test socket at the rear, 10-pole, optional
connection boxpossible
test coverpossible
automation
deliveryon stock

GLP1-g 331 | Test method » HV AC

type of testeronly high-voltage testers
high voltage AC0–6 kV˜ max. 100 mA
key switchfor HV-release
test terminalsHV1, HV2
test connectionstest pistols, 2-pole
automation
deliveryin 5 business days

GLP1-g 340 | Test method » HV AC

type of testeronly high-voltage testers
high voltage AC0–6 kV˜ max. 200 mA
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest pistols
 test socket at the rear, 10-pole, optional
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 341 | Test method » HV AC

type of testeronly high-voltage testers
high voltage AC0–6 kV˜ max. 200 mA
key switchfor HV-release
test terminalsHV1, HV2
test connectionstest pistols, 2-pole
automation
deliveryin 5 business days

GLP1-g 350 | Test method » HV AC

type of testeronly high-voltage testers
high voltage AC0–12 kV˜ max. 100 mA
key switchfor HV-release
test terminalsHV1, HV2
test connectionstest pistols
automation
deliveryin 5 business days

GLP1-g 360 | Test method » HV AC

type of testeronly high-voltage testers
high voltage AC0–15 kV˜ max. 50 mA
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionsHV1-tube, HV2-PE
test coverpossible
automation
deliveryorder-related manufacturing
high-voltage transformeroutside the test unit
Standard: Tubus vertikal
optional: Tubus horizontal





GLP1-g 370 | Test method » HV AC

type of testeronly high-voltage testers
high voltage AC0–30 kV˜ max. 30 mA
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionsHV1-tube, HV2-PE
test coverpossible
automation
deliveryorder-related manufacturing
high-voltage transformeroutside the test unit
Standard: Tubus vertikal
optional: Tubus horizontal

GLP1-g 380 | Test method » HV AC

type of testeronly high-voltage testers
insulation0–4 kV ˭ max. 1 GΩ
high voltage AC0–50 kV˜ max. 25 mA
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionsHV1-tube, HV2-PE
test coverpossible
automation
deliveryorder-related manufacturing
high-voltage transformeroutside the test unit
Standard: Tubus vertikal
optional: Tubus horizontal

GLP1-g 620 | Test method » GB · IR

type of testeronly safety testers ALL-IN-1
PE/GB1–10 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
test terminalsL1, N, PE
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 630 | Test methods » GB · IR

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
test terminalsL1, N, PE
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 720 | Test methods » IR · HV AC

type of testeronly safety testers ALL-IN-1
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest pistols
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 730 | Test methods » IR · HV AC

type of testeronly safety testers ALL-IN-1
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max. 100 mA
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest pistols
 test socket at the rear, 10-pole, optional
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 820 | Test methods » IR · HV DC

type of testeronly safety testers ALL-IN-1
insulation0–4 kV ˭ max. 1 GΩ
high voltage DC0–4 kV ˭ max. 10 mA
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest pistols
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 830 | Test methods » IR · HV DC

type of testeronly safety testers ALL-IN-1
insulation0–6 kV ˭ max. 10 GΩ
high voltage DC0–6 kV ˭ max. 10 mA
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest pistols
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 831 | Test methods » IR · HV DC

type of testeronly safety testers ALL-IN-1
insulation0–6 kV ˭ max. 10 GΩ
high voltage DC0–6 kV ˭ max. 20 mA
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest probe
 test socket at the rear, 10-pole, optional
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 840 | Test methods » IR · HV DC

type of testeronly safety testers ALL-IN-1
insulation0–10 kV ˭ max. 10 GΩ
high voltage DC0–10 kV ˭ max. 6 mA
safety concepttwo-channel
test terminalsHV1, HV2
test connectionstest pistols
automation
deliveryin 5 business days

GLP1-g 920 | Test methods » IR · HV AC · HV DC

type of testeronly safety testers ALL-IN-1
insulation0–4 kV ˭ max. 1 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
high voltage DC0–4 kV ˭ max. 10 mA
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest pistols
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 930 | Test methods » IR · HV AC · HV DC

type of testeronly safety testers ALL-IN-1
insulation0–4 kV ˭ max. 1 GΩ
high voltage AC0–6 kV˜ max. 20 mA
high voltage DC0–4 kV ˭ max. 10 mA
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsHV1, HV2
test connectionstest pistols
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 1011 | Test methods » GB· IR · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–10 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols
automation
deliveryin 5 business days

GLP1-g 1012 | Test methods » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–10 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols, 2-pole
automation
deliveryin 5 business days

GLP1-g 1020 | Test methods » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest probe
 test socket at the rear, 10-pole
connection boxpossible
test coverpossible
automationwith digital I/O
deliveryin 5 business days

GLP1-g 1021 | Test methods » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–10 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max. 100 mA
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols
automation
deliveryin 5 business days
Perfect for CE testEN60204 Machinery Directive 2006/42/EC
Special caseCaddy - perfect for mobile use

GLP1-g 1022 | Test methods » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–10 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max. 100 mA
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols, 2-pole
automation
deliveryin 5 business days
Perfect for CE testEN60204 Machinery Directive 2006/42/EC
Special caseCaddy - perfect for mobile use

GLP1-g 1030 | Test methods » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 1031 | Prüfmethoden » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
safety concepttwo-channel
test terminalsHV1, HV2
test connectionstest probe
 test pistols
automation
deliveryin 5 business days

GLP1-g 1032 | Test methods » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
safety concepttwo-channel
test terminalsHV1, HV2
test connectionstest probe
 test pistols, 2-pole
automation
deliveryin 5 business days

GLP1-g 1040 | Test methods » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
high voltage AC0–6 kV˜ max. 100 mA
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest probe
 test socket at the rear, 10-pole
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 1041 | Test methods » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max. 100 mA
key switchfor HV-release
safety concepttwo-channel
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols
automation
deliveryin 5 business days

GLP1-g 1042 | Test methods » GB · IR · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max. 100 mA
key switchfor HV-release
safety concepttwo-channel
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols, 2-pole
automation
deliveryin 5 business days

GLP1-g 1122 | Prüfmethoden » GB · IR · HV DC

type of testeronly safety testers ALL-IN-1
PE/GB1–10 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage DC0–4 kV ˭ max. 10 mA
key switchfor HV-release
test terminalsPE1/HV1/IR1, PE2/HV2/IR2 (GND)
test connectionstest probe
 test pistols, 2-pole
automation
deliveryin 5 business days

GLP1-g 1130 | Prüfmethoden » GB · IR · HV DC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage DC0–4 kV ˭ max. 10 mA
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 1220 | Prüfmethoden » GB · IR · HV DC · HV AC

type of testeronly safety testers ALL-IN-1
insulation0–1 kV ˭ max. 1 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
high voltage DC0–4 kV ˭ max. 10 mA
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest probe
 test socket at the rear, 10-pole
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 1221 | Prüfmethoden » GB · IR · HV DC · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
high voltage DC0–4 kV ˭ max. 10 mA
safety concepttwo-channel
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols
deliveryin 5 business days

GLP1-g 1222 | Test methods » GB · IR · HV DC · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max.3 mA safety
high voltage DC0–4 kV ˭ max. 10 mA
safety concepttwo-channel
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols, 2-pole
deliveryin 5 business days

GLP1-g 1224 | Test methods » GB · IR · HV DC · HV AC

type of testeronly safety testers ALL-IN-1
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest probe at connection box
 test socket at the rear, 10-pole
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 1225 | Prüfmethoden » GB · IR · HV DC · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max. 20 mA
high voltage DC0–4 kV ˭ max. 10 mA
key switchfor HV-release
safety concepttwo-channel
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols
deliveryin 5 business days

GLP1-g 1226 | Test methods » GB · IR · HV DC · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max. 20 mA
high voltage DC0–4 kV ˭ max. 10 mA
key switchfor HV-release
safety concepttwo-channel
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols, 2-pole
deliveryin 5 business days

GLP1-g 1230 | Test methods » GB · IR · HV DC · HV AC

type of testeronly safety testers ALL-IN-1
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest probe at connection box
 test socket at the rear, 10-pole
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 1231 | Test methods » GB · IR · HV DC · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max. 100 mA
high voltage DC0–4 kV ˭ max. 10 mA
key switchfor HV-release
safety concepttwo-channel
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols
deliveryin 5 business days

GLP1-g 1232 | Test methods » GB · IR · HV DC · HV AC

type of testeronly safety testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–6 kV˜ max. 100 mA
high voltage DC0–4 kV ˭ max. 10 mA
key switchfor HV-release
safety concepttwo-channel
test terminalsPE1, PE2
 HV1, HV2
test connectionstest probe
 test pistols, 2-pole
deliveryin 5 business days

GLP1-g 1320 | Test methods » GB · IR · Fct

type of testeronly safety & function testers ALL-IN-1
PE/GB1–30 A˜ 6/12 Veff
insulation0–1 kV ˭ max. 10 GΩ
function AC 1-phase0–250 V˜ max. 5 A
safety concepttwo-channel
test terminalsL1, N, PE
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 1520 | Test methods » GB · IR · HV AC · Fct

type of testeronly safety & function testers ALL-IN-1
high voltage AC0–6 kV˜ max.3 mA safety
function AC 1-phase0–250 V˜ max. 5 A
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g 1530 | Test methods » GB · IR · HV AC · Fct

type of testeronly safety & function testers ALL-IN-1
function AC 1-phase0–250 V˜ max. 5 A
key switchfor HV-release
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest probe
 test socket at the rear, 10-pole
connection boxpossible
test coverpossible
automation
deliveryin 5 business days

GLP1-g 1720 | Test methods » GB · IR · HV DC · Fct

type of testeronly safety & function testers ALL-IN-1
high voltage DC0–4 kV ˭ max. 10 mA
function AC 1-phase0–250 V˜ max. 5 A
safety concepttwo-channel
two-hand startpossible
test terminalsL1, N, PE
test connectionstest socket, country-specific
 test probe
 test socket at the rear, 10-pole, optional
connection boxpossible
automation
deliveryin 5 business days

GLP1-g Hybrid | Test methods » IR · HV AC · interlock

type of testeronly safety testers ALL-IN-1
insulation0–1 kV ˭ max. 10 GΩ
high voltage AC0–3 kV˜ max. 25 mA
key switchfor HV-release
two-hand startpossible
test terminalsassembled test cable
test connectionstest socket at the rear, 10-pole
deliveryin 5 business days
Special applicationTest of electric drives in service

If you haven’t found the perfect test device yet, please do not hesitate to contact us.

We would be pleased to help you find a custom solution:

Product consultant

Product consultant

Are you looking for a personal consultation?

Please contact us directly: +49 2372 901 25 40

Or simply send us your questions via e-mail.

E-mail inquiry

Description

Cutting-edge. Multifunctional. Compact.

The GLP1-g is designed to test electrical products and insulation systems of all kinds with just one device. Over 50 device configurations offer you solutions for a wide variety of testing tasks and will therefore also fulfill special application requirements.

GLP1-g test devices are ideally equipped for applications in manufacturing, laboratories, test fields, QA, automation and many more. The customized configuration of features lets you accomplish your business goals in an efficient, reliable and safe manner.

Discover a previously unattained level of performance in this class of devices. The enhanced model of the popular and proven GLP1 test device lets you create your custom test plans and store results directly in the device. A multitude of new features such as the impressive new 5″ touch display do not leave anything to be desired.

Our engineers only apply state-of-the-art technologies in our testers. As early as 1995, we became the first manufacturer to equip our test equipment with user-friendly touch displays.

In keeping with our corporate policy, all hardware and software is developed in-house and manufactured entirely at our Sauerland facilities, eliminating the risks of long supply chains. SCHLEICH is a technological pioneer in modern high-voltage, safety and functional testing.

A carefully balanced product portfolio.

More than 50 device configurations offer test method combinations for a wide range of applications:

High voltage testers.

High voltage testing represents a common area of application. It can be performed manually with high voltage test probes or at higher voltages inside a test cover or a test cage. Integration into a fully automatic test line poses no problems either.

A typical manual test configuration using high voltage test probes.


High voltage testing in a test cage. The test object is connected to the output of the high voltage transformer e.g. via a copper band.

High voltage testing above 12 kV with automatic grounding.


High voltage testing in a steel spheres bath.


Technology

Functionalities & Technology

Testing workstations
Depending on the area of application, you can conduct tests manually in a laboratory, at a repair work station or at a manual test benches:
Semi-automatic application for typical testing scenarios in manufacturing, e.g. with PE test probes.
Fully automatic integration into a production line.

Test connections
Different types of housings can be equipped with a test socket and/or a connection for test probes as well as sockets for high-voltage test pistols on the front plate of the device. Additional test connections, such as a 10-pole test plug, can be added to the back of the device if required. With these you can connect e.g. a universal terminal box, a test cover or test leads for your automated systems.

Test methods switch-over
In an ALL-IN-1 test device, built-in test methods will be automatically switched over to the test connections or test probes. Before the start of a test, all electrical connections of the test object can be connected to the test device to avoid time-consuming manual switching of the test leads after each individual test step. Your safety always comes first.

Dynamic data storage
Up to 1,000 test plan configurations and test results for a total of up to 790 test steps can be stored in the built-in memory.

Measurement technology
Precise and fast measurements, TRMS – true R.M.S. measurements, effective and peak value measurements, effective and apparent power measurement cosφ

Design

Device housing – robust industrial standard
Due to its compact ½ 19″- or 19″ industrial housing, the GLP1-g can be used for testing in the smallest of spaces while making the most of the available working space.
The device’s sturdy adjustable feet make sure it always keeps its proper position. It can also be installed in a 19″ cabinet using an optional mounting kit.

Menu

Simple and intuitive – the main menu
Navigating the device settings is straightforward and simple: you can load and customize test plans, adjust test parameters and change the device’s settings.

Just a touch
Test settings are entered on a touch display. Handling is straightforward and direct.

Details regarding the test parameters
A built-in help feature offers a detailed explanation of each test parameter and set value.

Plausibility checks for all entries
With automatic plausibility checks performed after each input, you can be sure that each test parameter or value entered is within the technical specifications of the test device. The results are accurate and reliable test runs.

Touch display

On-screen display – keeping it all in sight
The 5″ color TFT display shows all test steps and their results in outstanding detail in any lighting conditions – in sunlight or darkness.

Visualization for test devices with one test method
For single-method test devices, test results can be depicted in a variety of ways. Operators can choose their preferred mode of visualization.

Visualization for ALL-IN-1 test devices
All built-in test steps are listed vertically. The currently selected test step is highlighted in yellow. At the end of a test step, they change to either green (GO) or red (NOGO). You can also select a full screen view with details displayed for each test step.

Storing test results

Storing in Excel format – PrintCom 7
You can store test results directly on a connected PC in Excel format using PrintCom 7. PrintCom 7 lets you create test reports in your own personalized corporate design. You can connect your PC to the GLP1-g via RS232, USB or Ethernet.

Storing in CSV format – PrintCom G2
You can store test results directly on a connected PC in CSV format using PrintCom G2, letting you create a matching test report containing all essential information. You can connect your PC to the GLP1-g via Ethernet.

Remote control

Communication via I/O

  • digital I/O, (input/output 24 V to PLC)
  • start
  • stop
  • return results
  • and more …

Communication via RS232 / USB / LAN and SCHLEICH communication protocol

  • loading test plans from the network
  • transferring test plans with all test steps and parameters
  • initiating test sequences
  • receiving test results
  • setting outputs
  • checking inputs
  • and much more …

Communication via LabView drivers
The SCHLEICH-LabView driver lets your software communicate with the GLP1-g.
You can load a test plan, initiate a test and receive test results.

Features at a glance.

Measurement technology

  • precise measurement technology
  • TRMS – true R.M.S. measurements

PE/GB-resistance AC

  • 1 – 10, 1 – 30, 1 – 40, 1 – 75 A AC, adjustable test voltages, free of wear, electronically controlled
  • 6/12 V AC, adjustable open circuit voltage
  • 0 – 1.200 mΩ
  • PE/GB-resistance or voltage drop

PE/GB-resistance DC

  • 1 – 40 A DC, adjustable test voltages, electronically controlled
  • 0 – 6 Ω

Insulation resistance

  • 50 – 1,000 V DC, adjustable test voltages, free of wear, electronically controlled
  • max. 2 mA, security current limit
  • 100 KΩ – 10 GΩ

High voltage AC

  • 50 – 6,000, 100 – 12,000, 125 – 15,000, 250 – 30,000, 400 – 50,000 V AC, adjustable, free of wear, electronically controlled
  • up to 200 mA or with security current limit up to 3 mA
  • ramp-/voltage profile possible
  • true effective value and peak value measurement

High voltage DC

  • 50 – 4,000, 50 – 6,000, 1,000 – 10,000 V DC, adjustable, free of wear, electronically controlled
  • up to 20 mA or with security current limit up to 10 mA
  • effective and apparent power measurement
  • ramp-/voltage profile possible
  • peak value measurement

Function testing

  • 12 – 250 V AC, adjustable test voltages, free of wear, electronically controlled
  • safety transformer included
  • max. 5 A
  • cosφ
  • effective, reactive and apparent power measurement
  • max. 1,250 W, 1,250 VA, 1,250 VAR
  • short circuit test between L and N included

Basics

  • manufacturer’s calibration certificate, traceable to national standards included
  • built-in clock and calendar
  • USB, LAN and RS232

⇒ Find more details under Downloads.


Applications

Manual inspection

SCHLEICH_GLP1-g_manual inspection

The GLP1-g tester is immediately ready to perform your measurements. By means of the unique manual mode, all integrated test methods may directly be applied. There is no need to generate a test sequence in advance! You only select the requested test method and start the test.

Similar to a multimeter, the test results are displayed on the tester´s screen. Thus, the detailed evaluation of your test object is immediately possible.

Even long-term analyses, with a duration of several hours, may be run in this operating mode.


Production| Semi-automatic inspection

SCHLEICH_GLP1-g_production

Typical tests in production are either performed manually with test probes and/ or fully-automatic. Thanks to the convenient user guidance the GLP1 offers perfect testing conditions for these applications.

For the inspection of different kinds of test objects you can save up to 1000 test sequences in the GLP1-g, which can be opened and started by using the touch display.

Usually terminal boxes are used for connecting test object and tester.

SCHLEICH_GLP1-g terminal box

We offer standard terminal boxes in 4 different designs.


Serial production| Fully-automatic inspection

SCHLEICH_GLP1-g serial production

The GLP1-g may be easily integrated in your production line. The tester´s dimensions are based on a ½ 19“- or 19“-housing, which means, that it perfectly fits in your plant. Additional, flexible interfaces allow an entire remote control. A connection to a master PC or a PLC may easily be established.

You can store up to 1000 test sequences for several test objects. They can be activated via interface and the test may immediately be started. All test results are accessible via this interface and may be stored by the master PC in a central database. Furthermore it´s possible to save the test results locally on the tester or in a computer network.

To achive an even higher level of flexibility in automation or to control more complex processes we alternatively recommend our GLP2-testers.


Regular function tests with black boxes

The proper function of the single tests has to be regularly inspected. For this, a blackbox is used. The tester has to precisely determine the blackbox´s measured results. Otherwise the tester is locked.

The control measurement may be based on a Go/ No Go-specification or on reference values with tolerance specification.

SCHLEICH_GLP1-g Blackbox


Accessories

PrintCom G2

PC-Software for storing and printing test results
  • storing test results on a PC
  • printing test results

read more

PrintCom 7

PC-Software for storing and printing test results
  • transfer test results to a PC
  • storing the test results in EXCEL file
  • printing test results

read more

Two-Hand Operation

Protection against electrical hazards
  • dual-circuit safety with BG-approval
  • solid and stable
  • 2 different models

read more

Connection boxes

Connection panel for connecting your device under test
  • 1, 2, 3 or 4 test sockets for different country standards
  • quick pressure clamps for single leads
  • 4 mm laboratory sockets
  • high current socket for protective conductor test probe
  • for single-phase and three-phase test objects
  • customized solutions

read more

Black boxes

Dummy test used for standardized functionality control
  • for daily inspection
  • universal blackboxes
  • factory calibration, also according to DAkkS

read more

Warning lights

Warning and indication of hazardous test voltage
  • warning of hazardous test voltage
  • only required for touchable test objects
  • not necessary when test cover is used

read more

High-voltage test pistols

Safe testing with high voltage
  • for 6, 10 or 12 KV AC/DC
  • with integrated start switch
  • optional with 4-wire technology (4W)

read more

Test Probes

For manual PE, insulation resistance and leakage current tests
  • built-in start button
  • built-in 3-color LED

read more

Single Test Covers

Testing with protection against accidential contact
  • various sizes
  • ergonomic – smooth-running – versatile
  • robust industrial quality – long service life
  • up to Performance Level PLe
  • built-in result lights
  • plenty of space for adapter installations
  • optional: automatic opening – guard locking …

read more

Test Cabins

Testing with protection against accidential contact
  • with safety door or roller shutter
  • for large or bulky test objects
  • suitable for pallet trolleys
  • various sizes
  • robust industrial quality – long service life
  • up to Performance Level PLe
  • integrated door locking
  • custom solutions …

read more

Test facilities

Testing with protection against accidential touch
  • individual special solutions
  • multiple access doors
  • for large or bulky test objects
  • passable with fork lift truck
  • robust industrial quality – long service life
  • up to Performance Level PLe – evaluation with safety PLC
  • several emergency stop buttons and warning lights
  • integrated door locking …

read more

Test Tables

Individually designed and custom-made.
  • professional test tables:
  • according to BG-guidelines
  • customized for your test task

read more

Custom-made test covers

Test covers – individually designed and crafted to meet your specifications
  • individual customer-specific solutions of any kind, application and size

read more

Roller tables

Mobile test equipment use in your shop floor
  • mobility at testing
  • perfect for workshop applications
  • ergonomic design with storage space

read more

Safety Barriers

For securing the testing area
  • mobile workplace protection
  • with integrated emergency stop, warning lights
  • built-in 2-hand start

read more

Result Lights

Test result pass or fail
  • what is the test result?
  • green: go – pass – OK
  • red: no go – fail – not OK

read more

Foot Switch

Starting a test - Confirming a query
  • starting a test
  • confirming a query

read more

Luster terminal adapters

Contacting of 2-, 3- and 5-pole luster terminals
  • fast contacting with locking
  • up to 16 A

read more

Calibration Resistors

High precision for verifying measurement accuracy
  • precision resistors for the annual calibration
  • low drift
  • factory calibration
  • DAkkS calibration (optional)

read more

High-Voltage Relays

Switching and disconnecting high voltages safely
  • high-voltage relays
  • changeover matrixes
  • safe isolation
  • with single or double changeover contacts
  • SPDT “Single Pole Double Throw”
  • for rail mounting DIN50022
  • system components for DIY

read more

High-Voltage Cables

Safe conducting and distribution
  • for a variety of applications
  • cables up to 100 kV

read more

For further information please do not hesitate to contact our technical sales under:


print preview

Product comparison





type of tester
PE/GB
insulation
high voltage AC
high voltage DC
function AC 1-phase
function AC 3-phase
leakage current
luminaire test
key switch
safety concept
two-hand start
test terminals
test connections
connection box
test cover
automation
database
test plans
test results
communication
test report print-out
label print-out
scanner port
password protection
user management
SmartCalibration Ready
operating system
Operating System Technology Package
display
display Technology Package
delivery



Abbildung GLP2-BASIC GLP2-BASIC
read more
Abbildung GLP2-MODULAR GLP2-MODULAR
read more
Abbildung GLP2-Technologiepaket GLP2-Technology Package
read more
Abbildung HandHeld Abbildung GLP1-g Abbildung GLP2-BASIC Abbildung GLP2-MODULAR Abbildung GLP2-Technologiepaket Abbildung GLP3
HandHeld

GLP1-g

GLP2-BASIC

GLP2-MODULAR

GLP2-Technology Package

GLP3


portable – lightweight – PE test up to 10 A AC – insulation test up to 1,000 V – carrying strap – transport case – outdoor – PC software …

compact standard tester – up to 9 test methods in one device – table-top unit or 19″ rack – VDE/EN/UL – manual & automated testing – production – automation – laboratory – QA – service – PC software …

compact standard tester – up to 21 test methods in one unit – table-top unit or 19″ rack – VDE/EN/UL … – manual & automated testing – production – automation – laboratory – QA – network – protocol & label printing – Windows®

modular – customer-specific – VDE/EN/UL… – manual & automatic – production – automation – laboratory – QA – network – protocol & label printing – Windows®…

upgrade your GLP2-BASIC/MODULAR – external PC – Windows 10® – more convenience and intuitive operation – optimized visualization – even faster inputs …

TOP-Class · modular · customized · no limits · VDE/EN/UL/IEC … · production · automation · worldwide networking · databases · statistics · data import/export · Windows10® · complex systems …

read more   read more   read more   read more   read more   read more
only PE/GB-resistance testers
only insulation testers (IR)
only safety testers ALL-IN-1
only PE/GB-resistance testers
only insulation testers (IR)
only high-voltage testers
only safety testers ALL-IN-1
only safety & function testers ALL-IN-1
only high-voltage testers
only safety testers ALL-IN-1
only safety & function testers ALL-IN-1
only PE/GB-resistance testers
only insulation testers (IR)
only leakage-current testers
only high-voltage testers
only safety testers ALL-IN-1
only safety & function testers ALL-IN-1
only safety testers ALL-IN-1
only safety & function testers ALL-IN-1
1–10 A˜       6/12 Veff 1–10 A˜       6/12 Veff
1–30 A˜       6/12 Veff
1–40 A˜       6/12 Veff
1–40 A˭       12 V
1–75 A˜       6/12 Veff
1–30 A˜       6/12 Veff 1–10 A˜       6/12 Veff
1–30 A˜       6/12 Veff
1–200 A˜ ˭       up to 50 V
custom
1–10 A˜       6/12 Veff
1–30 A˜       6/12 Veff
1–200 A˜ ˭       up to 50 V
custom
0–1 kV ˭       max. 30 MΩ 0–1 kV ˭       max. 10 GΩ 0–1 kV ˭       max. 10 GΩ 0–1 kV ˭       max. 10 GΩ
up to 50 kV˭       up to 10 TΩ
custom
0–1 kV ˭       max. 10 GΩ
up to 50 kV˭       up to 10 TΩ
custom
0–6 kV˜       max.3 mA safety
0–6 kV˜       max. 100 mA
0–6 kV˜       max. 200 mA
0–12 kV˜       max. 100 mA
0–15 kV˜       max. 50 mA
0–30 kV˜       max. 30 mA
0–50 kV˜       max. 25 mA
0–6 kV˜       max.3 mA safety
0–6 kV˜       max. 100 mA
0–6 kV˜       max.3 mA safety
0–6 kV˜       max. 100 mA
custom
0–6 kV˜       max.3 mA safety
0–6 kV˜       max. 20 mA
0–6 kV˜       max. 100 mA
0–6 kV˜       max. 200 mA
0–12 kV˜       max. 100 mA
custom
0–4 kV ˭       max. 10 mA
0–6 kV ˭       max. 10 mA
0–6 kV ˭       max. 20 mA
0–10 kV ˭       max. 6 mA
0–6 kV ˭       max. 4 mA
0–6 kV ˭       max. 100 mA
0–6 kV ˭       max. 4 mA
0–6 kV ˭       max. 100 mA
custom
0–4 kV ˭       max. 10 mA
0–6 kV ˭       max. 10 mA
0–6 kV ˭       max. 20 mA
0–10 kV ˭       max. 6 mA
custom
0–250 V˜       max. 5 A 0–250 V˜       max. 5 A
230 V˜       max. 16 A
according to your requirements according to your requirements
according to your requirements according to your requirements
electronic products EN60990
medical products EN60601
UL compliant
1-phase
electronic products EN60990
medical products EN60601
UL compliant
1-phase
3-phase
up to 1 MHz
customized
electronic products EN60990
medical products EN60601
UL compliant
1-phase
3-phase
up to 1 MHz
customized
safety safety and function safety and function
dimming: analogue, digital, ECG communication, DALI...
parameterize, configure
LED test with plug&play comBOX
safety and function
dimming: analogue, digital, ECG communication, DALI...
parameterize, configure
LED test with plug&play comBOX
safety and function
dimming: analogue, digital, ECG communication, DALI...
parameterize, configure
for HV-release for HV-release for HV-release
two-channel two-channel two-channel two-channel
possible possible possible possible
L1, N, PE L1, N, PE L1, N, PE L1, N, PE
L1, L2, L3, N, PE
made to your specifications
L1, N, PE
L1, L2, L3, N, PE
made to your specifications
test socket, country-specific
test probe
test socket, country-specific
test probe
test pistols
test socket at the rear, 10-pole, optional
test socket, country-specific
test probe
test pistols
test socket at the rear, 10-pole, optional
according to your requirements according to your requirements
possible possible possible possible
possible possible possible possible
with digital I/O
with RS232 via SCHLEICH communication protocol
with USB via SCHLEICH communication protocol
with LAN via SCHLEICH communication protocol
with digital I/O
with RS232 via SCHLEICH communication protocol
with LAN via SCHLEICH communication protocol
with LAN via SCPI commands
with LAN via TCP/IP Socket Communication
with PROFIBUS
with PROFINET
with EtherCAT
with CANopen
made to your specifications
with digital I/O
with RS232 via SCHLEICH communication protocol
with LAN via SCHLEICH communication protocol
with LAN via SCPI commands
with LAN via TCP/IP Socket Communication
with PROFIBUS
with PROFINET
with EtherCAT
with CANopen
made to your specifications
with digital I/O
with RS232 via SCHLEICH communication protocol
with LAN via SCHLEICH communication protocol
with LAN via SCPI commands
with LAN via TCP/IP Socket Communication
with PROFIBUS
with PROFINET
with EtherCAT
with CANopen
made to your specifications
with digital I/O
with RS232 via SCHLEICH communication protocol
with LAN via SCHLEICH communication protocol
with LAN via TCP/IP Socket Communication
with PROFIBUS
with PROFINET
with EtherCAT
with CANopen
with CAN Automotive
with DeviceNet
made to your specifications
file system
SQL
file system
SQL
file system
SQL
ACCESS
SQL
ORACLE
import from PC, PLC, MES, ...
import from LabVIEW®
stored in the tester
import from PC, PLC, MES, ...
import from LabVIEW®
stored in the tester
stored in the tester and network
import from PC, PLC, MES, ...
import from LabVIEW®
import from ERP system, e.g. SAP®
stored in the tester
stored in the tester and network
import from PC, PLC, MES, ...
import from LabVIEW®
import from ERP system, e.g. SAP®
stored in the tester
stored in the tester and network
import from PC, PLC, MES, ...
import from LabVIEW®
import from ERP system, e.g. SAP®
stored in the tester
stored in the tester and network
import from PC, PLC, MES, ...
import from ERP system, e.g. SAP®
cached in the tester
transfer to PC, PLC, MES, ...
transfer to LabVIEW®
cached in the tester
transfer to PC, PLC, MES, ...
transfer to LabVIEW®
cached in the tester or network
transfer to PC, PLC, MES, ...
transfer to LabVIEW®
transfer to ERP system, e.g. SAP®
cached in the tester or network
transfer to PC, PLC, MES, ...
transfer to LabVIEW®
transfer to ERP system, e.g. SAP®
cached in the tester or network
transfer to PC, PLC, MES, ...
transfer to LabVIEW®
transfer to ERP system, e.g. SAP®
cached in the tester or network
transfer to PC, PLC, MES, ...
transfer to ERP system, e.g. SAP®
with ERP, MES, PLC, CAQ, ...
via LAN, WWW, OPC, ...
with ERP, MES, PLC, CAQ, ...
via LAN, WWW, OPC, ...
with ERP, MES, PLC, CAQ, ...
via LAN, WWW, OPC, ...
with ERP, MES, PLC, CAQ, ...
via LAN, WWW, OPC, ...
yes yes yes yes
yes yes yes yes
yes yes yes yes yes
yes yes yes yes yes yes
yes yes yes yes
yes yes
SCHLEICH embedded SCHLEICH embedded Windows Embedded®-PC in the tester Windows Embedded®-PC in the tester Windows 10®-19"-Industrial PC integrated
Stand-alone Windows 10®-PC
external Windows 10® PC
LED 7-segment touch color LCD 480 x 272 touch color LCD 800 x 480
PC monitor of any size
touch color LCD 800 x 480
PC monitor of any size
PC monitor of any size
touch monitor of any size
on stock in 5 business days on stock order-related manufacturing order-related manufacturing order-related manufacturing
